Specifications

主板

• NSB 7110W
• Support Intel® Xeon™ 5500/5600 series Processors, LGA1366 socket
• Support 4.8/5.86/6.4 GT/s QPI Speed
• Intel® 5520 and ICH10R Chipset

內存

• 6 x 240-pin DDR3 800/1066 DIMM Sockets, up to 24GB ECC® and ECC DDR3 SDRAM

網絡特點

• Swappable LAN Module
• LAN Chip: Intel® 82574L/82575EB/82598EB
• Support 10/100/1000 link speed
• LAN BYPASS: by model *Please see module list information in Datasheet (PDF)

擴展

• 1 x PCIe x8 Slot (Default)
• 2 x PCIe x4 Slot (Optional)
• 2 x PCI-X Slot (Optional)

I/O接口-前面板

• Support 2x16 Characters LCD module, PIO interface
• Power status / HDD status / LAN status / Bypass status LEDs
• 4 x 3.5" HDD Swappable bays
• 3 x LAN Module bays
• 2 x USB 2.0 ports
• 1 x RJ45 type Console port
• 1 x software button
• 1 x Managment LAN ports

I/O接口-后面板

• 2 x Swappable System FANs
• 1 x Expansion slot for PCIe x8
• 2 x Expansion slots for PCI-X (Optional)
• 2 x Expansion slots for PCIe x4 (Optional)
• 1 x VGA Port

存儲設置

• 1 x on-board CompactFlash socket
• 1 x USB-DOM device space
• 1 x SATA-DOM device space

電源輸入

• 460W 1+1 ATX Redundant Power Supply

體積

• Chassis Dimension: 426mm x 580mm x 88mm
• Carton Dimension: 640mm x 800mm x 310mm

重量

• Without Packing: 19kg
• With Packing: 25kg

認證

• CE approval
• FCC Class A
• UL
